Background
To support the digital transformation of Hong Kong's Plumbing and Drainage industry, the Construction Industry Council (CIC), in collaboration with the Hong Kong Plumbing and Sanitary Ware Trade Association (HKPSWTA), is proud to launch the BIM Objects Library – Plumbing and Drainage Objects. This initiative aims to encourage the widespread adoption of BIM in the local industry by providing free resources that are universal, standardized and tailored to local specifications in Hong Kong. The first phase of the library focuses on pipe fittings, with plumbing accessories to be released in the next phase.

Key Features
- Local Relevance: Designed specifically for Hong Kong's plumbing and drainage practices.
- High Level of Detail: BIM objects are developed to LOD 400 in Revit 2020 format.

Comprehensive Coverage
- 15 types of pipe fittings based on general specifications commonly used in Hong Kong
- 8 types of pipe materials included for versatile application

Download the Complete Package
Users can download the full library as a ZIP file, which contains:
1 - Look-Up Table of the Library
2 - Individual Library Elements
3 - Naming Convention Documentation
4 - OmniClass Table of the Library
5 - Shared Parameters (Text File)
6 - User Manual
7 - Revit Template File with all P&D fittings and tailored project settings

Click the link below to download the BIM Objects Library – Plumbing and Drainage Objects
https://drive.google.com/file/d/1KO7b1nhYvopwxeZg6bz95e6m6BRqEYSg/view?usp=sharing

This package is designed to streamline BIM workflows and ensure consistency across plumbing and drainage projects.

Disclaimer
The BIM Objects Library – Plumbing and Drainage Objects is developed under an open license scheme. The Construction Industry Council (CIC) and the Hong Kong Plumbing and Sanitary Ware Trade Association (HKPSWTA) do not accept any liability for loss or damage arising from the use of this library. Users are advised to apply the content at their own risk and discretion.

Acknowledgements
Special thanks to the following contributors for their invaluable support in developing the Plumbing and Drainage Objects Library:
- Hong Kong Plumbing and Sanitary Ware Trade Association (HKPSWTA)

Go to Master List

CIC BIM Object Sheet Template: Excel Format

Users are recommended to adjust/remove the attribute values from any BIM objects from CIC Objects Library to satisfy their project-specific needs.

For BIM objects that are not comply with BIM Harmonisation Guideline, the basic information of the BIM object would not be displayed. However, the basic information is included in Object Sheets and BIM object files.
